Engine
Tractors are equipped with durable and proven engines with three or four cylinders and cover power range from 39 to 90 HP. Designed for easy maintenance and low operating costs.
Gearbox
The tractors are offered with various type of transmissions depending on model, 8/2 Sliding Mesh or 8/8 Partial Synchromesh or 12+12 Syn-chromesh in 2WD and 4WD options.
Hydraulics
All models employ mechanically regulated hydraulics, featuring two lever, automatic Draft and Position control with mix control.
COMPAX tractors
The new tractors in the COMPAX range are compact, easy to operate, and versatile machines for professionals and come in open or cab versions. COMPAX tractors are particularly suitable for summer and winter maintenance of villages, company premises, and sports grounds, as well as for gardening.
Engine
Tractors are equipped with durable and proven engines with three or four cylinders and cover power range from 39 to 90 HP. Designed for easy maintenance and low operating costs.
Gearbox
The tractors are offered with various type of transmissions depending on model, 8/2 Sliding Mesh or 8/8 Partial Synchromesh or 12+12 Syn-chromesh in 2WD and 4WD options.
Hydraulics
All models employ mechanically regulated hydraulics, featuring two lever, automatic Draft and Position control with mix control.
COMPAX tractors
The new tractors in the COMPAX range are compact, easy to operate, and versatile machines for professionals and come in open or cab versions. COMPAX tractors are particularly suitable for summer and winter maintenance of villages, company premises, and sports grounds, as well as for gardening.
| Parameters | Units | Global Compax 26 | 29 |
|---|---|---|
| ENGINE | ||
| Type/Emission standard | • | 4 Stroke & Water Cooled / Stage IIIA |
| Max. power (R120/EHK 120) | kW | 17.9 | 20.1 |
| HP | 24 | 27 | |
| Rated Speed | rpm | 2700 | 2800 |
| No. of Cylinders / Valves | • | 4 Cylinders/8 |
| Aspiration | • | Natural |
| Bore / Stroke | mm | 73x78 |
| Displacement | cm3 | 1306 |
| Max. Torque | Nm | 72@2200 |
| TRANSMISSION | ||
| Type | • | Sliding Mesh |
| Clutch type | • | - | Single (dry fritction plate)/Diaphragm type |
| Shifting | • | Manual |
| No. of Gears (F/R) | • | 6/2 |
| Max. Speed | km/h | 24.68 |
| Min. Speed | km/h | 1.68 |
| PTO | ||
| Type | • | Two speed |
| Rear PTO revolutions | rpm | 540/810 | 540/1000 |
| Max. Power of Rear PTO | HP | 19.1 | 24 |
| Rear PTO shaft grooves | • | 1-3/8 SAE STD |
| HYDRAULICS | ||
| Type | • | ADDC |
| Gear Pump Capacity | l/min | 18 |
| Rear Hydraulic remotes (Quickcouplers) | • | Spool Valve (Double Acting) |
| Three Point Hitch | ||
| Control / Category | • | ADDC/CAT-1 |
| Max. Lift Capacity | kg | 7.5 |
| Platform | ||
| Roof / Mirrors | • | ROPS/Yes |
| Steering Wheel | • | Fixed |
| Electrical System | ||
| Beacon | • | Optional |
| 7-pole socket | Yes | |
| Undercarriage | ||
| Drive system | • | 4 WD |
| Operating brakes | • | OTB |
| Fuel tank | l | 18 |
| Brakes | • | Oil Immersed Break |
| Tires | • | Front - 5x12, Rear - 8.3x20 |
| Other Specification | ||
| Max. Front Ballast | kg | 60 |
| Max. Length / Width / Height | mm | 2450/1095/1376 |
| Min. Ground Clearance | mm | 305 |
| Wheel base | mm | 1420 |
